Built around the traverses of the Enduro World Series our Vortex wheels redefine what Enduro wheels are.
With a generous 33mm internal width Vortex wheels increase tyre volume and maximise the available grip on offer. Using an asymmetric design we have equalised spoke tensions and built a package that leaves descents in its wake, whilst cutting down weight where it isn’t needed for energy sapping climbs. To compensate for the differences in wall length and strength of an asymmetric design, the wall thicknesses have been proportioned to balance out impact forces equally. The Vortex offers offset wheel benefits, without compromise.
At the core of our Vortex wheels are our new and improved instantaneous 120 point pick up MT Supadrive and MT Front hubs, with sealed bearings and super wide spaced flanges for increased stiffness and durability.
100% hand built and pre fitted with tubeless tape, Vortex wheels are tubeless ready from the box.
Coloured decal kits available aftermarket.
Front Standard – 100 x 15mm thru
Front Boost – 110 x 15mm thru
Rear Standard – 142 x 12mm thru, 135 x 9mm QR
Rear Boost – 148 x 12mm thru
Rear Super Boost – 157 x 12mm thru
Spokes – Black double butted stainless spokes
Nipples – Black brass
Rim Depth – 20.75mm
Internal Width – 33mm
External Width – 38mm
Rim Joint type – Sleeved
Front Hub Spacing – 100mm or 110mm Boost
Rear spacing – 135/142mm or 148mm Boost
Drillings – 32H
Freehub – Shimano HG or SRAM XD versions
Freehub Body – Alloy
Drive System – Supadrive
Disc Mount – 6 Bolt
Spoke pattern – Front 2x, Rear 3X
Recommended Tyre size – 2.35-2.8″
Tubeless – Tubeless ready
Colour – Stealth Black
Vortex 27.5″ Front Boost, MT Front Boost 110 – 15x110mm Disc Hub, 32H, Black DB Spokes, Vortex 27.5″ Front, MT Front Disc Hub, 32H (QR/15mm Ft), Black DB Spokes
Vortex 27.5″ Supadrive Boost XD, MT Supadrive Boost 148 Disc Hub, 32H, SRAM XD, Black DB Spokes, Vortex 27.5″ Supadrive Boost, MT Supadrive Boost 148 Disc Hub, 32H, Shimano HG, Black DB Spokes, Vortex 27.5″ Supadrive XD, MT Supadrive 142Thru/135QR Disc Hub, 32H, SRAM XD, Black DB Spokes, Vortex 27.5″ Supadrive XD, MT Supadrive 157Thru Disc Hub, 32H, SRAM XD, Black DB Spokes, Vortex 27.5″ Supadrive, MT Supadrive 142Thru/135QR Disc Hub, 32H, Shimano HG, Black DB Spokes, Vortex 27.5″ Supadrive, MT Supadrive 157Thru Disc Hub, 32H, Shimano HG, Black DB Spokes
